Laminated pouch packing machine

Name: Laminated pouch packing machine
Brand: SUN PACKAGING SYSTEMS
Price: 175000.00 INR
Availability: InStock

Price 175000.00 INR/ Piece

Get a Price/Quote

MOQ : 1 Inch

Laminated pouch packing machine Specification

Product Type
3 OR 4 SIDE SEAL MACHINE

Material
Stainless Steel (contact parts), MS powder coated (structure)

Application
Other

Packaging Material
Other

Computerized
Yes

Automatic Grade
Automatic

Drive Type
Servo motor drive

Voltage
220V / 50 Hz

Weight (kg)
Approx. 850 kg

Dimension (L*W*H)
3200 mm x 1150 mm x 1850 mm

Capacity
Up to 70 pouches per minute (depending on pouch size and material)

Color
Metallic Grey

Safety Features
Emergency stop, interlocks, overload protection

Pouch Width Range
40 mm - 125 mm

Max. Reel Width
250 mm

Operating Temperature Range
5C - 40C

Sealing Type
Three-side or four-side seal options

Compressed Air Required
6 CFM @ 6 Bar

Human Interface
Touchscreen control panel

Registration System
Photoelectric mark sensor for accurate print registration

Cutting System
Pneumatic rotary/fixed knife system

Pouch Length Range
50 mm - 200 mm

Film Thickness
60 - 120 microns

Filling Range
1 gm - 250 gm (depending on product and attachment)

Noise Level
< 72 dB(A)

Roll Unwind Diameter
Max 350 mm

Laminated pouch packing machine Trade Information

Minimum Order Quantity
1 Inch

Supply Ability
1 Inch Per Week

Delivery Time
7 Days

Laminated pouch packing machine About

Experience an astounding leap in packaging with the 3 or 4 Side Seal Machine (Model Sunflex - 4S250 Laminate Pouch + Photocell), now on sale and in high demand! This extraordinary, peerless machine offers three-side or four-side seal versatility, competitive pricing, and is designed to deliver up to 70 pouches per minute. Key features include PLC controls, servo motor drive, precise photoelectric registration, and easy changeover, all packed into a robust stainless steel and MS powder-coated structure. Perfect for food, pharmaceutical, chemical, and cosmetic industries, it promises reliability, safety, and efficiency that stands unmatched in its class.

Versatile Applications & Special Features

The SUNFLEX - 4S250 Laminate Pouch + Photocell machine excels across industries, including food, pharmaceuticals, chemicals, and cosmetics. Its adaptability with various laminated and heat-sealable films makes it highly versatile. Special features such as automatic roll unwinding, pneumatic rotary knife system, and a human-friendly touchscreen control panel elevate productivity. The photoelectric mark sensor guarantees accurate print registration, ensuring every pouch is perfectly sealed. Application media range from powders and granules to liquids, catering to diverse packaging needs.

Certifications and Sample Policy Details

The 3 or 4 Side Seal Machine is manufactured according to stringent industry standards, ensuring premium quality and robust performance. Prospective buyers can request machine samples under the supplier's sample policy, with list price or rate details provided upon inquiry. The asking price is highly competitive in the market, reflecting the superior technology and build quality. For exporters, manufacturers, or service providers, this machine comes with complete documentation and support for certification needs, ensuring a seamless procurement process.

FAQ's of 3 OR 4 SIDE SEAL MACHINE (MODEL SUNFLEX - 4S250 LAMINATE POUCH + PHOTOCELL):

Q: How does the photoelectric mark sensor benefit the packaging process?

A: The photoelectric mark sensor ensures precise print registration, so each pouch is accurately sealed and visually perfect, enhancing product presentation and reducing waste.

Q: What types of pouch materials can be used with the SUNFLEX - 4S250 machine?

A: The machine is compatible with laminated films and heat-sealable materials such as PET/PE and PET/ALU/PE, making it suitable for a wide range of packaging applications.

Q: When is this machine most suitable for use across industries?

A: This machine is best utilized in food, pharmaceuticals, chemical, and cosmetic packaging, where high output and stringent hygiene standards are essential.

Q: Where can the machine be installed and operated efficiently?

A: It is designed for industrial and manufacturing settings where space and infrastructure align with its dimensions (3200 x 1150 x 1850 mm) and requirements for 220V/50Hz power and compressed air.

Q: What is the installation process for the SUNFLEX - 4S250?

A: Installation involves connecting the machine to the required power and compressed air supply, setting up the reel and materials, and configuring the operating parameters via the touchscreen interface. Detailed instructions and support are provided with purchase.

Q: How is safety ensured during operation?

A: Safety features include emergency stop buttons, interlocks, and overload protection mechanisms to safeguard operators and equipment during all stages of use.
